Caratteristiche Tecniche
| CPU | 13th Gen Intel® Core™ i9/i7/i5/i3 Processor (Raptor Lake-S) |
|---|---|
| Chipset | Intel® R680E |
| RAM | 4 x DDR5 4800MHz UDIMM, up to 128GB |
| LAN | 2 x Intel® I226 2.5GigE LAN |
| I/O | 4 x USB 3.2, 4 x COM (RS232/422/485), 16 x Isolated DI, 16 x Isolated DO |
| Storage | 2 x Front-access M.2 Key M SSD Tray (2280, PCIe x4), 4 x SATAIII |
| Expansion | 1 x PCIe x16 Slot with PCIe 4.0 x16 Signal, 2 x PCIe x16 Slot with PCIe x4 Signal, 2 x M.2 Key B Socket (2280/3042/3052), 1 x M.2 Key E Socket (2230), 1 x mini PCIe |
| Operative range | -25°C to 45°C |
| Power | DC 16V to 50V; 16-mode Software Ignition Control |
| Notes | Out-of-Band: MCU Nuvoton NUC980 |
