Caratteristiche generali
| CPU | 11th Gen Intel® Xeon®/Core™ i7/i5 Processor (Rocket Lake-S) |
|---|---|
| Chipset | Intel® W580 |
| RAM | 4 x DDR4 2933MHz SO-DIMM, up to 128GB |
| LAN | 1 x 2.5G RJ45, 1 x GigE RJ45 |
| I/O | 6 x USB 3.2, 1 x USB 2.0 (Internal), 4 x COM (RS232/422/485), 16 x Isolated DI, 16 x Isolated DO |
| Storage | 4 x Front Access 2.5″ HDD Tray, 1 x M.2 Key M, 1 x M.2 Key B |
| Expansion | 2 x PCIe x8 (Gen4, x16 Mechanical), 3 x PCIe x4 (Gen3, x16 Mechanical), 2 x mPCIe, 1 x M.2 Key E |
| Operative range | -25°C to 60°C |
| Power | 9V to 55V Wide Range DC Input, Ignition Control |
| Notes | – |
