Caratteristiche Tecniche
| CPU | 11th Gen Intel® Xeon®/Core™ i7/i5 Processor (Rocket Lake-S) |
|---|---|
| Chipset | Intel® W580 |
| RAM | 4 DDR4 SO-DIMM, up to 128GB |
| LAN | 1x Intel I225IT 2.5G LAN, 1x Intel I219LM GigE LAN supports iAMT |
| I/O | 6x USB 3.2 Gen2, 4x COM RS-232/422/485, 32 Isolated DIO: 16 DI, 16 DO |
| Storage | SATA 4 SATA III (6Gbps) support software RAID 0, 1, 5, 10, 1 M.2 Key M Socket (2280, PCIe Gen 4 x4), 1 M.2 Key B Socket (2280, PCIe x2, share with expansion) Storage Device – 4 Front-access 2.5″SSD/HDD Tray, 1 M.2 Key M Socket |
| Expansion | 2 Mini PCIe sockets for PCIe/USB/SIM Card/Optional mSATA PCIe, 3 PCIe Slot: – 1 PCIe x16 slot with x16 signal (Gen4), 2 PCIe x16 slot with x4 signal, 1 M.2 Key B Socket (3042/3052/2280), 1 M.2 Key E Socket (2230) |
| Operative range | -25°C to 60°C |
| Power | 9V to 55V, DC-in |
| Notes | – |
