Caratteristiche generali
| CPU | Quad Core Intel® Xeon®/Core™ i7/i5/i3 Processor (Skylake-S/Kaby Lake-S) |
|---|---|
| Chipset | Intel® C236 |
| RAM | 2 DDR4 2133MHz SO-DIMM, up to 32GB |
| LAN | 6 Independent GigE LAN with 4 M12 IEEE 802.3at PoE+ |
| I/O | 8 x USB 3.0, 4 x COM RS-232/422/485 (ESD 8KV), 32 Isolated DIO |
| Storage | 4 x Front-access 2.5″ SSD/ HDD Tray, 1 x CFast Socket, 1 x M2DOM |
| Expansion | 3 x mPCIe |
| Operative range | Depends On CPU |
| Power | 6V to 36V DC Power Input with 80V Surge Protection, Configurable Ignition Power Control |
| Notes | – |
