Caratteristiche Tecniche
| CPU | 14th gen, Raptor Lake-S Refresh |
|---|---|
| Chipset | Intel® R680E |
| RAM | 2 x DDR5 5600MHz SO-DIMM, up to 96GB (ECC/Non-ECC) |
| LAN | 2 x Intel® I226 2.5GigE LAN supports TSN |
| I/O | 4 x USB 3.2 Gen 2 Type A; 1 x USB 3.2 Gen 2×2 Type-C supports max 20Gbps data transfer (15W, 5V/3A); 2 x COM RS-232/422/485; 2 x HDMI 2.1: Up to 4096 x 2304 @60Hz; 1 x DP: Up to 3840 x 2160 @60Hz; 4 x DP: Up to 7680 x 4320 @60Hz (By requested MXM); 32 x Isolated DIO: 16 x DI, 16 x DO |
| Storage | 2 x SATA III with 2 Front Access 2.5″ HDD Tray, 1 x M.2 Key M |
| Expansion | 1 x PCIe x18 with x8 Signal; 1 x M.2 Key B Socket (2280/3042/3052, PCIe/USB 3, default/SATA); 1 x M.2 Key E Socket (2230, PCIe/USB) |
| Operative range | – 35W TDP CPU : -25°C ÷ 55°C – 65W TDP CPU : -25°C ÷ 45°C |
| Power | DC 9V ÷ 55V |
| Notes | – |
