Caratteristiche generali
| CPU | 10th Gen Intel® Xeon®/Core™ i9/i7/i5/i3 Processor (Comet Lake-S) |
|---|---|
| Chipset | Intel® W480E |
| RAM | Dual Channel DDR4 SO-DIMM 2933MHz, up to 64GB |
| LAN | 2 x GigE RJ45 |
| I/O | 6 x USB 3.2, 3 x COM (RS-232/422/485), 16 x Isolated DI, 16 x Isolated DO |
| Storage | 2 x SATA3 (6 Gb/s) Front-Access HDD/SSD Tray, 1 x M.2 Key M, 1 x M.2 Key B, 1 x mSATA (6Gb/s) |
| Expansion | 1 x MXM PCIe x16, 1 x PCIe x4 (EVS-2010), 1 x PCI (EVS-2001), 1 x mPCIe, 1 x M.2 Key B, 1 x M.2 Key E |
| Operative range | -40°C to 55°C |
| Power | 9V to 50V DC Power Input with 80V Surge Protection, Configurable Ignition Power Control |
| Notes | – |
