Caratteristiche Tecniche
| CPU | Intel Atom® x6425RE Processor (Elkhart Lake) |
|---|---|
| Chipset | – |
| RAM | 1 DDR4 3200MHz SO-DIMM, up to 32GB |
| LAN | LAN 1 Intel® Ethernet Controller I210 supports GigE LAN, LAN 2 Intel® Ethernet Controller I225 supports 2.5GigE LAN |
| Switch Ethernet | sLAN 1 to sLAN 6 10/100/1000 Base LAN port, sLAN 9 & sLAN 10 100/1000 Base SFP port |
| I/O | Serial 4 COM RS-232/422/485(ESD 8kV) USB – 2 USB 3.1 – 2 USB 2.0 LED HDD, WLAN, Power, WWAN, P1, L/A, F/O SIM Card 1 External Nano SIM Card Socket |
| Storage | 1 M.2 Key M Socket (2280, PCIe x2/SATA) |
| Expansion | 1 M.2 Key E Socket (2230) |
| Operative range | -25°C to 70°C |
| Power | 9V to 55V |
| Notes | – |
