Caratteristiche Tecniche
| CPU | Industrial-grade NXP i.MX 8M Plus Quad Core Arm Cortex-A53 Processor, embedded Neural Processing Unit, up to 2.3 TOPS AI performance |
|---|---|
| Chipset | – |
| RAM | 4GB LPDDR4 Memory |
| LAN | 2 x GigE LAN with 1 TSN supported |
| I/O | 2 x USB 3.0 for Vision, 2 x COM RS-232/422/485,1 x Micro USB console debug port, 5-bit GPIO (Optional),2 x Nano SIM Card Socket, 6 x Antenna for WiFi/BT/5G/4G/LTE/GPRS/UMTS |
| Storage | 1 x eMMC 32GB, 1 x Micro SD |
| Expansion | 1 x M.2 Key B Socket (3042/3052), 1 x Full-size Mini PCIe Socket |
| Operative range | -25+70°C |
| Power | 9V to 55V DC Power Input |
| Notes | – |
