Caratteristiche Tecniche
| CPU | 13th Generation Intel® Core™ i9/i7/i5/i3 Processor (Raptor Lake-S) |
|---|---|
| Chipset | Intel® R680E Chipset |
| RAM | 2 x DDR5 4800MHz SO-DIMM up to 96GB |
| LAN | 1 x Intel® I219LM GigE LAN supports iAMT, 1 x Intel® I226-IT 2.5GigE LAN, 4 x 2.5GigE IEEE 802.3at (25.5W/48V) PoE by Intel®I226 |
| I/O | 6 x USB 3.2 Gen 2; 1 x USB 3.2 Gen 2×2; 1 x USB Type-C; 4 x COM RS-232/422/485; 32 x Isolated DIO (16 DI, 16 DO); 3 x External Nano SIM Card Socket |
| Storage | 4 x SATA III (6Gbps) support software RAID( 0,1,5,10); 1 x M.2 Key M Socket (2280, PCIe 4.0 x4); 4 x Front-access 2.5″SSD/HDD Tray |
| Expansion | 2 x PCIe x8; 2 x PCIe x4; 1 x Mini PCIe sockets for PCIe/USB/SIM Card/Optional mSATA; 1 x M.2 Key B Socket (2280/3042); 1 x M.2 Key B Socket (2280/3052); 1 x M.2 Key E Socket (2230) |
| Operative range | -20°C ÷ 45°C (-4°F to 113°F), with System Fan |
| Power | DC 12V ÷ 50V Power Input |
| Notes | – |
