Caratteristiche Tecniche
| CPU | 16-core 12th Generation Intel® Core™ i9/i7/i5/i3 Processor (Alder Lake-S), 24-core 13th Gen Intel® Core™ i9/i7/i5/i3 Processor (Raptor Lake-S) |
|---|---|
| Chipset | Intel® R680E |
| RAM | 2 x DDR5 4800MHz SO-DIMM, up to 64GB |
| LAN | 4 x 2.5GigE IEEE 802.3at PoE+ by Intel® I226; 1 x Intel I219LM; 1 x Intel I226-IT |
| I/O | 6 x USB 3.2 Gen 2; 1 x USB 3.2 Gen 2×2; 4 x COM RS-232/422/485; 32 x Isolated DIO (16 DI, 16 DO) |
| Storage | 4 x SATA III; 1 x M.2 Key M Socket (2280) |
| Expansion | Up to 4 x PCIe Slots; 1 x M.2 Key B Socket (2280/3042), 1 x M.2 Key B Socket (2280/3052), 1 x M.2 Key E Socket (2230); 1 x Mini PCIe |
| Operative range | -20°C to 45°C |
| Power | DC 12V to 50V Power Input |
| Notes | – |
