General Features
| CPU | 12th Gen Intel® Core™ i9/i7/i5/i3 Processor (Alder Lake-S), 13th Gen Intel® Core™ i9/i7/i5/i3 Processor (Raptor Lake-S) |
|---|---|
| Chipset | Intel® R680E |
| RAM | Dual Channel DDR4 3200MHz SO-DIMM, up to 64GB |
| LAN | 4 x 2.5GigE IEEE 802.3at (25.5W/48V) PoE + 1 x 2.5 GigE and 1 x Intel® I219LM |
| I/O | 6 x USB 3.2 Gen 2, 4 x COM (RS-232/422/485), 8 x Isolated DI, 8 x Isolated DO |
| Storage | 2 x SATA3 (6 Gb/s), 1 x M.2 Key M, 1 x mSATA |
| Expansion | 1 x mPCIe, 1 x M.2 Key B, 1 x M.2 Key E |
| Operative range | Depends on CPU |
| Power | 9V to 50V DC Power Input with 80V Surge Protection, Configurable Ignition Power Control |
| Notes | – |
