Caratteristiche generali
| CPU | 10th Gen Intel® Xeon®/Core™ i9/i7/i5/i3 Processor (Comet Lake-S) |
|---|---|
| Chipset | Intel® W480E |
| RAM | 2 DDR4 2933MHz Memory, up to 64GB (ECC/Non-ECC) |
| LAN | 1 x Intel® I219LM GigE LAN supports iAMT 14.0; 1 x Intel® I210 GigE LAN; 4 x GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I350 |
| I/O | 6 x USB 3.2; 4 x COM (RS-232/422/485); 32 x Isolated DIO; 16 x DI, 16 x DO; 1 x VGA : Up to 1920 x 1200 @60Hz; 1 x DVI-D : Up to 1920 x 1080 @60Hz; 2 x DisplayPort : Up to 4096 x 2304 @60Hz; 3 x External Nano SIM Card Sockets |
| Storage | 2 x SATA III (6Gbps) support S/W RAID 0, 1; 2 x SATA III (Mini PCIe type, 6Gbps); 1 x M.2 Key M Socket (2280, PCIe x4);1 x Micro SD Card Push-in/Push-out ejector; 2 x Front-access 2.5″ SSD/HDD Tray |
| Expansion | 1 x PCIe x16 slot; 2 x Mini PCIe sockets for PCIe/USB/SIM Card/Optional mSATA; 1 x M.2 Key B Socket (3042/3052); 1 x M.2 Key E Socket (2230) |
| Operative range | 35W TDP CPU : -40°C ÷ 75°C, Fanless 65W TDP CPU : -40°C ÷ 55°C, Fanless 80W & 95W TDP CPU : -40°C ÷ 55°C, with Fan Sink |
| Power | 9V ÷ 50V DC Power Input with 80V Surge Protection, Configurable Ignition Power Control |
| Notes | – |
