General Features
| CPU | 10th Gen Intel® Xeon®/Core™ i9/i7/i5/i3 Processor (Comet Lake-S) |
|---|---|
| Chipset | Intel® W480E |
| RAM | Dual Channel DDR4 SO-DIMM 2933MHz, up to 64GB |
| LAN | 2 x GigE RJ45 |
| I/O | 6 x USB 3.2, 1 x USB 2.0, 4 x COM (RS-232/422/485), 16 x GPIO |
| Storage | 2 x SATA3 (6 Gb/s), 1 x M.2 Key M |
| Expansion | 1 x PCI, 2 x mPCIe, 1 x M.2 Key B, 1 x M.2 Key E |
| Operative range | Depends on CPU |
| Power | 9V to 50V DC Power Input with 80V Surge Protection, Configurable Ignition Power Control |
| Notes | – |
