General Features
| CPU | 8 Cores 9th Generation Intel® Xeon®/Core™ i7/i5/i3 (Coffee Lake Refresh) |
|---|---|
| Chipset | Intel® C246 Chipset |
| RAM | 2 DDR4 2666MHz SO-DIMM, up to 64GB (ECC/Non-ECC) |
| LAN | Dual 10GigE SFP+ LAN support up to 10Gbps data rate, 6 Independent GigE LAN with 4 IEEE 802.3at PoE+ |
| I/O | 6 USB 3.1, 4 COM RS-232/422/485, 16 Isolated DIO |
| Storage | 1 CFast Socket, 2 Front-access 2.5″ SSD/HDD Tray, 1 M.2 Key M Socket |
| Expansion | 2 2.5 SSD Tray, 2 SIM Socket, 1 CFast Socket, 2 M.2 Socket |
| Operative range | -40°C to 55°C Operating Temperature |
| Power | 6V to 36V DC Power Input with 80V Surge Protection, Configurable Ignition Power Control |
| Notes | – |
