General Features
| CPU | 8 Cores 9th Generation Intel® Xeon®/Core™ i7/i5/i3 (Coffee Lake Refresh) |
|---|---|
| Chipset | Intel® C246 |
| RAM | 2 DDR4 2666MHz SO-DIMM, up to 64GB (ECC/Non-ECC) |
| LAN | 4 Independent GigE LAN, iAMT 12.0 supported |
| I/O | 6 x USB 3.1, 4 x COM RS-232/422/485 (ESD 8KV), 16 GPIO |
| Storage | 2 x 2.5″ SSD/HDD Bracket, 1 x CFast Socket, 1 x M.2 Key M |
| Expansion | 2 x mPCIe, 1 x M.2 Key E, 2 x SUMIT |
| Operative range | Depends On CPU |
| Power | 6V to 36V DC Power Input with 80V Surge Protection, Configurable Ignition Power Control |
| Notes | – |
