General Features
| CPU | Intel® Xeon® E3-1505M v5/Core™ i7-6820EQ Processor (Skylake-H) |
|---|---|
| Chipset | Intel® CM236 |
| RAM | 2 DDR4 2133MHz SO-DIMM, up to 32GB (ECC/Non-ECC) |
| LAN | Dual 10 GigE LAN, up to 10Gbps data rate, 6 Independent GigE LAN with 4 IEEE 802.3at PoE+ |
| I/O | 32 Isolated DIO, 6 USB 3.0, 4 COM RS-232/422/485 (ESD 8KV) |
| Storage | 2 Front-access 2.5″ SSD Tray |
| Expansion | 4 Mini PCIe/mSATA |
| Operative range | -20°C to 55°C |
| Power | 10V to 36V DC-in with 80V Surge Protection, Configurable Ignition Power Control |
| Notes | – |
