Caratteristiche generali
| CPU | Quad Core Intel® Xeon®/Core™ i7/i5/i3 Processor (Skylake-S/Kaby Lake-S) |
|---|---|
| Chipset | Intel® C236 |
| RAM | 2 DDR4 2133MHz SO-DIMM, up to 32GB (ECC/Non-ECC) |
| LAN | 10 Independent GigE LAN with 8 IEEE 802.3at PoE+, 4-port X-coded M12 |
| I/O | 8 x USB 3.0, 4 x COM RS-232/422/485 (ESD 8KV), 32 Isolated DIO |
| Storage | 2 x Front-access 2.5″ SSD/HDD Tray, 1 x CFast Socket, 1 x M.2 Key M |
| Expansion | 3 x mPCIe |
| Operative range | Depends On CPU |
| Power | 6V to 36V DC Power Input with 80V Surge Protection, Configurable Ignition Power Control |
| Notes | – |
