General Features
| CPU | Intel® Core™ i7-6700/i7-6700TE/i5-6500/i5-6500TE/i3-6100/i3-6100TE Processor (Skylake-S) |
|---|---|
| Chipset | Intel® C236 |
| RAM | 2 DDR4 2133MHz SO-DIMM, up to 32GB |
| LAN | 9 Independent GigE LAN with 4 IEEE 802.3at PoE+ |
| I/O | 6 x USB 3.0, 4 x COM RS-232/422/485, 16 Isolated DIO |
| Storage | 2 x Front-access 2.5″ SSD/HDD Tray, 1 x CFast Socket, 1 x M2DOM |
| Expansion | 3 x mPCIe, 2 x SUMIT |
| Operative range | Depends On CPU |
| Power | 6V to 36V DC-in, 80V Surge Protection, Configurable Ignition Power Control |
| Notes | – |
