Caratteristiche generali
| CPU | 8-core NVIDIA Carmel ARM® v8.2 64-bit CPU |
|---|---|
| Chipset | – |
| RAM | 1 LPDDR4x DRAM, up to 64GB |
| LAN | 10/100/1000 Base-T Ethernet GigE LAN, RJ45 Connector; 4xIEEE 802.3at (25.5W/48V) GigE PoE+ LAN, RJ45 Connector |
| I/O | 4 USB 3.0 Type A, 2x CAN, 8 x connectors for GMSL 1/GMSL 2 automotive cameras |
| Storage | 1 M.2 Key M Socket (2280); 1 eMMC 5.1, 32GB 1 Micro SD (External) |
| Expansion | 1 M.2 Key B Socket (3042/3052); 1 M.2 Key E Socket (2230) |
| Operative range | 30W TDP Mode : -20°C to 70°C; MAX TDP Mode : -20°C to 55°C |
| Power | 9V to 50V DC Power Input |
| Notes |
