Technical Features
| CPU | 8th/9th Generation Intel® Core™ Processors |
|---|---|
| Chipset | Intel® H310/Q370 Chipset |
| RAM | DDR4 2400/2666MHz up to 64GB |
| LAN | 1 x Intel I219LM for Q370 / I219V for H310; 3 x Intel I210AT |
| I/O | 4 x USB 3.1 Gen2; 6 x USB2.0; 2 x RS232; 1 x HDMI (auto-detection); 4 x DP (from MXM) |
| Storage | 1 x SATA III connector with 1 x 2.5” SSD tray (with 6 USB 2.0, there is only 1 x SSD tray); 1 x M.2 M key supports 2242/2280 slot (PCIe Gen3 x4/SATA) |
| Expansion | 1 x M.2 M key supports 2242/2280 slot (PCIe Gen3 x4/SATA); 1 x M.2 B key supports 3052 slot (PCIe x1/USB3.1 Gen1); 1 x M.2 E key supports 2230 slot (PCIe x1/USB2.0) |
| Operative range | 0°C to 55°C |
| Power | 19V DC-in |
| Notes | MXM 3.1 slot, Type-A/B up to 110W |
